47. Interceptors, part 1, concepts

Freebie

Published 26 February 19

The Interceptor pattern was originally introduced by Pedestal, but has since been adopted by several other projects in the Clojure world. It’s an extremely useful design tools to be familiar with, and while they may seem a bit strange at first, Interceptors are suprisingly straightforward.

This episode introduces the interceptor concept, including the context map, queue, and stack. Clojure’s persistent queues are explored, and to round off we look at how interceptors deal with error handling.

browse source code

Namespaces

Cheat sheet

Interceptor:

{:name ::my-interceptor
 :enter (fn [ctx] ctx)
 :leave (fn [ctx] ctx)
 :error (fn [ctx exception] ctx)}

Enqueue/execute

(require '[lambdaisland.interceptor :refer [enqueue execute]])

(-> {:initial :context}
    (enqueue [interceptor-1 interceptor-2])
    (execute))

Interceptors are a programming pattern first introduced by the Pedestal library, where it is used to implement HTTP request handling. Since then there have been several independent implementations. re-frame uses a version of interceptors for its event handling, Finnish Clojure shop Metosin released a highly optimized version called Sieppari, Eric Normand came up with some variations on the theme in his own implementation.

Despite that interceptors have seen limited adoption outside of a few narrow use cases tied to specific libraries. This is a shame, because interceptors are uniquely suitable for modelling all kinds of processes, including dynamic dispatching and asynchrony.

In this episode I’ll first explain interceptors in their own right using a simplified implementation specifically written to help demonstrate the concepts involved. Once you’ve gotten a good grasp of the fundamentals I’ll go over some of the specific features in Pedestal’s implementations.

To follow along, clone the GitHub repository for this episode, you can find the link in the show notes, and then open the interceptor-demo namespace, and start a REPL in your editor of choice.

I’ve already included the lambdaisland.interceptor namespace, pulling in all public functions. The first two, enqueue and execute, are really all you need, but the others will come in handy to see step by step how things work under the hood.

(ns lambdaisland.interceptor-demo
  (:require [lambdaisland.interceptor :refer [enqueue
                                              execute
                                              process-enter
                                              process-error
                                              process-leave
                                              enter-1
                                              leave-1
                                              error-1
                                              ctx-summary]]))

Let’s look at an example to get a birds eye view of what things look like. When dealing with interceptor there’s always a single map called the context that gets passed around throughout the process. This snippet starts with a context map containing a :count of 0. It then enqueues two interceptors, the first will increases the counter by 1, and second by 10. It then calls execute on the context, so the interceptors actually run. The end result is again the context map, but updated by the two interceptors.

(-> {:count 0}
    (enqueue [{:enter (fn [ctx]
                        (update ctx :count + 1))}
              {:enter (fn [ctx]
                        (update ctx :count + 10))}])
    execute)
;;=>
{:count 11,
 :lambdaisland.interceptor/queue <-()-<,
 :lambdaisland.interceptor/stack ()}

So these two maps in enqueue are what we call interceptors. They can optionally have a :name, as well as :enter, :leave, and :error functions.

These different functions are executed at different parts of the process. First each interceptor’s :enter functions is called, passing the context from one to the next. Once execute has processed all :enter functions it will shift into reverse, calling each interceptor’s :leave function in reverse order.

If an error occurs while processing :enter or :leave, then execute will switch to a different track, calling the :error function of any interceptor that still needs to leave.

Don’t worry if that still sounds a little abstract, I’ll run you through the process step by step so you can see for yourself what’s happening.

{:name ::my-first-interceptor
 :enter (fn [ctx] ctx)
 :leave (fn [ctx] ctx)
 :error (fn [ctx ex] ctx ex)}

Let’s take a step back and drop the call to execute. I’ll also give these interceptors names so you can identify them. The first one is called :add-1, the second :add-10.

Next I’m enqueueing these two interceptors onto the context map, but I’m not yet executing them. I’m just setting up the battle plan, adding these two interceptors to the context, so I can execute them later on.

(-> {:count 0}
    (enqueue [{:name  :add-1
               :enter (fn [ctx]
                        (update ctx :count + 1))}
              {:name  :add-10
               :enter (fn [ctx]
                        (update ctx :count + 10))}]))
;; =>
;; {:count 0,
;;  :lambdaisland.interceptor/queue
;;  <-({:name :add-1,
;;      :enter #function[lambdaisland.interceptor-demo/eval13368/fn--13369]}
;;     {:name :add-10,
;;      :enter #function[lambdaisland.interceptor-demo/eval13368/fn--13371]})-<}

Now the context has gotten an extra key: :lambdaisland.interceptor/queue. The printed representation has these ASCII art arrows at the front and back, indicitating that this is a Clojure PersistentQueue. Queues don’t get the same attention that maps, vectors, and sets get, but they are just as much a part of Clojure’s immutable data structures.

A queue is very similar to a Clojure list, the difference is that with a list elements are added and removed from the front, so they behave as a kind of stack, whereas with a queue elements are added to the back, and removed from the front. You can also say that lists are “Last in first out” or LIFO, whereas queues are “First in first out” or FIFO.

(-> {:count 0}
    (enqueue [{:name  :add-1
               :enter (fn [ctx]
                        (update ctx :count + 1))}
              {:name  :add-2
               :enter (fn [ctx]
                        (update ctx :count + 10))}])
    :lambdaisland.interceptor/queue
    type)
;;=> clojure.lang.PersistentQueue

Unlike vectors or maps there’s no reader syntax for creating queue literals, instead you start with the empty queue, and add elements onto it with conj.

The arrows at the front and back show the direction in which the elements move through the queue. Each call to conj inserts an element at the tail end, and each call to pop removes an element from the front. pop returns the new queue, to get the element at the front just call first.

(-> clojure.lang.PersistentQueue/EMPTY
    (conj :a) ;; => <-(:a)-<
    (conj :b) ;; => <-(:a :b)-<
    (conj :c) ;; => <-(:a :b :c)-<
    (pop)     ;; => <-(:b :c)-<
    (conj :d) ;; => <-(:b :c :d)-<
    (conj :e) ;; => <-(:b :c :d :e)-<
    (pop)     ;; => <-(:c :d :e)-<
    (pop)     ;; => <-(:d :e)-<
    (pop)     ;; => <-(:e)-<
    (pop)     ;; => <-()-<
    )

Ok so you have a context including a queue of interceptors, let’s start executing some of them.

The execute function is pretty straightforward, it calls process-enter, process-leave, and process-error, corresponding with the three stages that execute goes through.

(defn execute
  "Execute the context.

  This assumes interceptors have been enqueued with [[enqueue]]. It will run
  through the `:enter` stage of all interceptors in the queue, and then through
  their `:leave` stage in reverse order.

  If at some point an exception is raised, then it will skip the rest of the
  `:enter` or `:leave` stage, and instead run the `:error` stage of all
  interceptors that still had to leave."
  [context]
  (-> context
      process-enter
      process-leave
      process-error))

Each of these you can further split into individual steps. For instance process-enter processes the :enter stage of all interceptors in the queue by recursively calling enter-1, passing the context from one to the next. The rest of the code here is just error and boundary checking.

Knowing this you can call enter-1 directly to see what things look like after entering the first interceptor.

process-leave and process-enter similarly call leave-1 and error-1, so you can call these fine grained functions from the REPL to see step by step what happens.

(defn process-enter
  "Process the `:enter` stage of all interceptors on the queue.

  Run through all interceptors on the queue, executing their `:enter` stage and
  moving them from the queue to the stack, until the queue is empty or an error
  occured."
  [{::keys [queue] :as context}]
  (if (seq queue)
    (let [new-context (enter-1 context)]
      (if (::error new-context)
        new-context
        (recur new-context)))
    context))

Let me first refactor this a bit. I’ll create a helper function so I can easily create a few interceptors to test with. The interceptor adds one amount to the count in the :enter stage, and another amount in the :leave stage. That way if I pick my numbers right it’s easy to see which parts have executed and which haven’t.

(defn make-interceptor [x y]
  {:name  (keyword (str "add-" x "-" y))
   :enter (fn [ctx]
            (update ctx :count + x))
   :leave  (fn [ctx]
            (update ctx :count + y))})

Now add them both to the queue, ready to be executed. The count so far is still zero, since none of the interceptors have actually run.

(-> {:count 0}
    (enqueue [(make-interceptor 1 2)
              (make-interceptor 10 20)]))
;;=>
;; {:count 0,
;;  :lambdaisland.interceptor/queue
;;  <-({:name :add-1-2,
;;      :enter #function[lambdaisland.interceptor-demo/make-interceptor/fn--13426],
;;      :leave #function[lambdaisland.interceptor-demo/make-interceptor/fn--13428]}
;;     {:name :add-10-20,
;;      :enter #function[lambdaisland.interceptor-demo/make-interceptor/fn--13426],
;;      :leave
;;      #function[lambdaisland.interceptor-demo/make-interceptor/fn--13428]})-<}

This is a bit noisy though. To better see what’s going on I’ve added a ctx-summary function, which replaces the interceptor maps with just their names, and it replaces the :lambdaisland.interceptor/queue key with just :queue. Now you can see at a glance what’s in the queue.

(-> {:count 0}
    (enqueue [(make-interceptor 1 2)
              (make-interceptor 10 20)])
    ctx-summary)

;;=> {:count 0, :queue <-(:add-1-2 :add-10-20)-<}

Time to process the first :enter stage using enter-1. Now several things have happened. The :count has increased by 1, so it seems like the :enter stage of the first interceptor has run. This interceptor has now been removed from the queue, instead added onto a list called “stack”.

(-> {:count 0}
    (enqueue [(make-interceptor 1 2)
              (make-interceptor 10 20)])
    enter-1
    ctx-summary)

;;=> {:count 1, :queue <-(:add-10-20)-<, :stack (:add-1-2)}

Call enter-1 again and now the second interceptor’s :enter stage has increased the :count to eleven. The second interceptor also got moved from the queue to the stack, so the queue is now empty, while the stack contains both interceptors, but in reverse order, since stacks are “first in last out”.

(-> {:count 0}
    (enqueue [(make-interceptor 1 2)
              (make-interceptor 10 20)])
    enter-1
    enter-1
    ctx-summary)

;;=> {:count 11, :queue <-()-<, :stack (:add-10-20 :add-1-2)}

Now that the queue is empty, the :leave stage will kick in, so let’s call leave-1 and see what happens.

Rather than processing the queue, the leave stage processes the stack, popping interceptors off the stack, and running their :leave functions.

Notice that the last interceptor to :enter was the first to :leave. They’re kind of like sandwiches in that way, and while they’re quite different from Ring middleware, you can see that in this sense they’re a little similar, since each interceptor can “wrap” the interceptors that follow.

(-> {:count 0}
    (enqueue [(make-interceptor 1 2)
              (make-interceptor 10 20)])
    enter-1
    enter-1
    leave-1
    ctx-summary)
;;=> {:count 31, :queue <-()-<, :stack (:add-1-2)}

Finally run the :leave stage of the last interceptor. Now all interceptors have finished executing, the stack is empty, and the count is 33.

(-> {:count 0}
    (enqueue [(make-interceptor 1 2)
              (make-interceptor 10 20)])
    enter-1
    enter-1
    leave-1
    leave-1
    ctx-summary)
;;=> {:count 33, :queue <-()-<, :stack ()}

This is the same result as if you would have called execute directly, running through the whole interceptor process.

(-> {:count 0}
    (enqueue [(make-interceptor 1 2)
              (make-interceptor 10 20)])
    execute
    ctx-summary)
;;=> {:count 33, :queue <-()-<, :stack ()}

So far so good, now let’s look at some of the more interesting things you can do with interceptors. One interesting thing to note is that the full context is available to each interceptor, including the queue and stack, and so both can be manipulated. This means for instance that an interceptor can queue extra interceptors.

In this example I’m starting out with just a single interceptor, but this interceptor calls enqueue again to add ten more interceptors to the queue.

(-> {:count 0}
    (enqueue [{:name :enqueue-more
               :enter
               (fn [ctx]
                 (enqueue ctx (repeat 10 (make-interceptor 1 0))))}])
    enter-1
    ctx-summary)

This is commonly used in web applications to do routing. A router interceptor will inspect the request, and enqueue appropriate interceptors to handle the given URL and request method.

(-> {:request {:uri "/hello"}}
    (enqueue [router])
    execute)

Another thing you can do with the queue is empty it (or simply remove it), to stop any interceptors left in the queue from executing. This way the :enter stage finishes, and :leave kicks in, calling :leave on any interceptors left in the stack. This is common enough that Pedestal has a helper function for it called terminate.

(defn terminate [ctx]
  (dissoc ctx :lambdaisland.interceptor/queue))

Can you follow what’s going on here? The :enqueue-more interceptor uses its :enter stage to enqueue a hundred identical interceptors. Each of them increases the count by one, unless the count is already greater than twenty, then it calls terminate to remove the remainder of the queue, effectively cutting any remaining processing of the :enter stage short.

(-> {:count 0}
    (enqueue [{:name :enqueue-more
               :enter
               (fn [ctx]
                 (enqueue ctx (repeat 100
                                      {:name :add-1
                                       :enter
                                       (fn [ctx]
                                         (if (> (:count ctx) 20)
                                           (terminate ctx)
                                           (update ctx :count inc)))})))}])

    execute)

Now let’s see what happens when an error occurs. I’ll first create this interceptor, aptly called “boom!” which simply throws an exception when its enter stage gets called.

(def boom!
  {:name :BOOM!
   :enter (fn [ctx]
            (throw (ex-info "Oops!" {:very :sorry})))})

The handle-error interceptor doesn’t have an :enter or :leave function, but instead has an :error function. Note that unlike :enter and :leave this one takes two arguments, the second being the caught exception.

This error handler interceptor will flip the sign of the count, so we can see that something went wrong.

(def handle-error
  {:name :handle-error
   :error (fn [ctx ex]
            (update ctx :count * -1))})

Next I’ll enqueue the error handler first. Then I’ll put some regular interceptors that increase the count, then the interceptor that blows up, and finally another count interceptor.

(-> {:count 0}
    (enqueue [handle-error
              (make-interceptor 1 2)
              (make-interceptor 10 20)
              boom!
              (make-interceptor 100 200)])
    )

Ok, now let’s walk through this step by step to see what happens. First run the :enter stage of the first three interceptors. So far things are straightforward, the first didn’t have an :enter stage, the second and third increased the :count to eleven. Now the exploding interceptor is up next.

(-> {:count 0}
    (enqueue [handle-error
              (make-interceptor 1 2)
              (make-interceptor 10 20)
              boom!
              (make-interceptor 100 200)])
    enter-1
    enter-1
    enter-1
    ctx-summary)
;;=>
{:count 11,
 :queue <-(:BOOM! :add-100-200)-<,
 :stack (:add-10-20 :add-1-2 :handle-error)}

Now run the next one. You’ll notice two things: the queue is gone, and there’s an :error key added to the context.

{:count 11,
 :stack (:BOOM! :add-10-20 :add-1-2 :handle-error),
 :error
 {:stage :enter,
  :interceptor :BOOM!,
  :exception-type :clojure.lang.ExceptionInfo,
  :very :sorry}}

At this point execute will unwind the stack, just like when processing the leave stage, but instead of calling :leave, it will call each interceptor’s :error key.

The same happens if an exception happens during the :leave stage. Any remaining interceptors on the stack will have their :error stage called. Note that an exception in an :enter stage can be handled by an :error function on the same interceptor, whereas if the exception happens in a :leave function, then the current interceptor’s :error handler doesn’t run, because the interceptor is no longer on the stack.

(-> {:count 0}
    (enqueue [handle-error
              (make-interceptor 1 2)
              (make-interceptor 10 20)
              boom!
              (make-interceptor 100 200)])
    process-enter
    process-error
    ctx-summary)

So far I’ve stuck to my own minimalist implementation to demonstrate the basic concepts involved in dealing with interceptors. It’s a great implementation to study, it’s only a hundred-odd lines of straightforward code, but it does lack some of the features that you get with Pedestal, key among them the ability to “go async”.

I’ll explore Pedestal’s interceptors in detail in the next episode, stay tuned!
